0.1mm Thick Transparent Tpu Eva Adhesive Film For Textile Fabric
Product Details
| Material: | 0.1mm 10s Thick Transparent Tpu Eva Hot Melt Adhesive Film For Textile Fabric And Lamination | Thickness: | 0.1mm / 10s |
|---|---|---|---|
| Width: | 30cm/50cm/90cm/customizable | Cerification: | OEKO-TEX STANDARD 100, Ce |
| Hardness: | Soft | Packing: | 100M/ROLL |
| Release: | Glassine Release Paper | Model Number: | FMO-FILM1 |
| Supply: | Make To Order | ||
| Highlight |
Transparent Tpu Eva Adhesive Film,0.1mm Thick Eva Adhesive Film,Textile Fabric Eva Adhesive Film |
||
Product Description
0.1mm 10s thick transparent tpu eva hot melt adhesive film for textile fabric and lamination
HDPE Mesh Point Film Adhesive Non Woven Rolls for Bonding Garment
| Specification | |
| Item Name | EVA Hot Melt Adhesive Film |
| Material | 100%PO |
| Width | 30cm / 500cm / 90cm / customizable |
| Color | White |
| Thickness | 0.1mm / 10s |
| Coating | EVA |
| Release liner | Glassine release paper |
| Application | Textile fabric / industrial lamination |
| Fusing Conditions | 1) temperature:125℃-135℃ 2) pressure: 0.3-0.6mpa 3) time: 5-15 s |
| Product Features | 1) Eco-frienldy 2) High quality 3) good bond strength and durable stability |
| MOQ | 2000 square meters or as per current stock |
| Packing | Rolls packed by strong carton |
| Port | Shanghai |
| Q1: How can I get your sample? |
| A1: You will get our free sample with technical data sheet. |
| Q2: Can you do OEM/ODM? |
| A2: Yes, your requirement for OEM or ODM is welcomed and can be satisfied. |
| Q3: How long is your lead time? |
|
A3: Samples: 1 - 2 days Available Stock: 1 - 2 days LCL: 7 - 10 days FCL: 10 - 15 days |
| Q4: What is your payment terms? |
| A4: Your payment via T/T, L/C, D/A, D/P or Western Union is acceptable. |
| Q5: How's your quality control process? |
|
A5: Your ordered goods will go through: our Internal and External Quality Control
> Internal quality control: Sample of your goods will be tested by our lab on it’s bond-strength, shrinkage, dry cleaning and washing features to ensure it complies with industrial standards. |
Frequently Asked Questions
Q1: What is the difference between TPU/EVA film and PA or PES coated interlining?
A: The film is a standalone adhesive layer with no base cloth, so it adds essentially no weight or stiffness to the laminate. A coated interlining carries adhesive on a woven or nonwoven base, which also changes the handle. Use film when you want bonding only, interlining when you need structure.
Q2: What are the fusing conditions for a 0.1 mm film?
A: 125-135 °C, 0.3-0.6 MPa and 5-15 seconds. Film bonds fast because there is no base cloth to heat through, so start at the lower end of the time range and run a peel test before production.
Q3: What does the glassine release paper do?
A: Glassine carries the film through cutting and pre-tacking without the adhesive sticking to itself or the machine. It also allows pre-cut shapes for labels and trims to be handled before final bonding.
Q4: What widths and MOQ are available?
A: 30 cm, 50 cm, 90 cm and custom widths, packed 100 m per roll in strong cartons. MOQ is 2,000 square meters or current stock, and samples are free with a technical data sheet.
Values reflect our technical data and lamination trials. OEKO-TEX Standard 100 and CE certified.
